9.2.2.6 Resume request responded with Release with Redirect, with UE context relocation

The following figure describes a UE triggered NAS procedure responded by the network with a release with redirect, with UE context relocation.

1. The UE resumes from RRC_INACTIVE, providing the I-RNTI allocated by the last serving gNB.

2. The gNB, if able to resolve the gNB identity contained in the I-RNTI, requests the last serving gNB to provide UE Context data.

3. The last serving gNB provides the UE context.

4. The gNB may move the UE to RRC_CONNECTED (and the procedure follows step 4 of Figure 9.2.2.4.1-1), or send the UE back to RRC_IDLE (in which case an RRCRelease message is sent by the gNB), or send the UE back to RRC_INACTIVE, including a release with redirect indication (as assumed in the following).

5. If loss of DL user data buffered in the last serving gNB shall be prevented, the gNB provides forwarding addresses.

6./7. The gNB performs path switch.

8. The gNB keeps the UE in RRC_INACTIVE state by sending RRCRelease with suspend indication, including redirection information (frequency layer the UE performs cell selection upon entering RRC_INACTIVE).

9. The gNB triggers the release of the UE resources at the last serving gNB.

NOTE 1: Upon receiving the release with redirect, the higher layers trigger a pending procedure so the UE tries to resume again after cell selection.
